Description
Dimensions and weight Dimensions (mm) Unit, W×D×H 430 × 630 × 217 Unit Weight (kg) 70.8
Input AC Parameters Operating Frequency, Nom 50 or 60 Hz (Factory Default is 50 Hz ) Factory Default Voltage 230 VAC Operating Voltage Range Without Battery Operation 176 to 288 VAC (100 to 176 VAC with power derating) Maximum Allowable Voltage 288 VAC Input Frequency Without Battery Operation 40 to 70 Hz
Output AC Parameters AC-AC Efficiency 94% User-configurable Voltage 200/208/220/230/240 VAC Factory Default Voltage 230 VAC Frequency 50 Hz Waveform Pure Sinewave Main Mode Overload ≤ 105% continuous ; 105 to 125% for 5 minutes; 125 to 150% for 60 seconds; > 150% minimum 200 ms
Internal Battery Charger Current 2.25 A (default), maximum 5 A Type Valve-regulated, non-spillable, lead acid Qty x V x Rating 16 x 12V x 9.0 AH Back-up Time at Full Load 7 5,5 Back-up Time at Half Load 18,5 14,5
Bypass Protection Limits Upper-limit Selections + 10%, + 15%, + 20%; default + 10%. Lower-limit Selections- 10%, – 15%, – 20%; default – 15% Disable-bypass Operation When the input frequency prevents synchronous operation
General Operating Temperature Full power up to 40 ºC (up to 50 ºC with derating) Storage Temperature-20 to +60 °C ( contain batteries will be from -15 to 40 °C.) Relative Humidity 0 to 95% non-condensing Operating Elevation Up to 3,000 m (9,842.5 ft) at 25°C (77°F) without derating Audible Noise <55 dBA Safety IEC 62040-1: 2008 (First Edition) + Am 1:2013, EN 62040-1:2008+A1:2013 EMI/EMC/C-Tick EMC IEC/EN/AS 62040-2 2nd Ed (Cat 2 – Table 6); FCC Part 15 (Class A), CISPR22 Class A (RFI) ESD IEC/EN EN61000-4-2, Level 4, Criteria B Radiated Susceptibility IEC/EN EN61000-4-3, Level 3, Criteria A Electrical Fast Transient IEC/EN EN61000-4-4, Level 4, Criteria B Surge Immunity IEC/EN EN61000-4-5, Level 4, Criteria A; ANSI C62.41 Category B Transportation ISTA Procedure 1E
POD Model Number PD5-CE6HDWRMBS Amp Rating 50 A Includes Two ICE320 C19 16 A / 250 V Sockets, Six C13 10 A / 250 V Sockets
